Price
US $8-10
Model
AS-TD113
MOQ
100 piece

Item specifics

Membrane Material
EDPM, Rubber,Silica Gel
Connector
3/4"NPT male thread
Length
500/750/1000mm

Review

Description

Tube Diffuser AS-TD113 Introduction

Category: Biochemical Tank -Aeration Diffuser
Brand: AquaSust

Model: AS-TD113

Size: 113mm

Bubble type: Fine bubble

Material: EDPM, Rubber, Silica Gel


tube diffuser For Pulp And Paper Industry Wastewater Secondary Treatment

Tube Diffuser AS-TD113 Advantage

1. Significantly improve oxygen transfer efficiency: AS-TD113 fine bubble diffuser significantly improves oxygen transfer efficiency by providing smaller bubble size, optimizing the dissolution process of oxygen in water.
2. Design advantages of smaller bubbles: Smaller bubbles mean a larger contact area between air and water, which increases the opportunity for oxygen to contact water and improves dissolution efficiency.
3. Suitable for wastewater with high organic load: It is especially suitable for treating industrial wastewater with high organic load, such as wastewater from textile, food processing and chemical industries, to improve the treatment effect.
4. Reduce energy consumption during aeration: The generation of small bubbles helps reduce energy consumption during aeration because they are able to transfer oxygen into the water column more efficiently at lower pressures.
5. Promote microbial activity: High oxygen transfer efficiency promotes microbial activity, accelerates the biodegradation process of organic matter, and improves treatment capacity and effluent quality.
6. Optimize energy efficiency: AS-TD113 fine bubble diffuser not only optimizes energy efficiency in the wastewater treatment process, but also reduces the overall energy consumption of the system.
7. Achieve environmental protection and cost-effectiveness: Through efficient oxygen transfer and reduced energy consumption, the AS-TD113 fine bubble diffuser helps achieve more environmentally friendly and cost-effective wastewater management.
8. Adapt to a variety of wastewater treatment needs: The diffuser can adapt to various types and compositions of wastewater treatment needs, providing flexible solutions.

Tube Diffuser AS-TD113  Application

AS-TD113 Tube diffusers play a key role in the secondary treatment of pulp and paper industry wastewater. Wastewater from this industry is characterized by high concentrations of organics, color and suspended solids, placing extreme demands on the wastewater treatment system. AS-TD113 Tube diffusers increase the dissolution rate and transport efficiency of oxygen by generating fine air bubbles, which are essential for promoting the growth and activity of microorganisms in the wastewater. These microorganisms effectively remove pollutants from the wastewater by breaking down the organic matter in the wastewater into harmless substances such as carbon dioxide and water through a biodegradation process.
Parameter
Item number
AS-TD63
AS-TD93
AS-TD113
Bubble type
Fine Bubble
Fine Bubble
Fine Bubble
Tube diameter(mm)
63
93
113
Material
Special Formula EPDM with UV Protector import from Germany /Silicon Membrane
Tube material :Acrylonitrile-butadiene-styrene with UV Protector (ABS)
Length
500/750/1000mm
Connector
3/4NPT
Flow range(m³/h)
2-14
5-20
6-28
Bubble Size(mm)
1-2
1-2
1-2
Service Area(m²)
0.75-2.5
1.0-3.0
1.5-2.5
